Fire Compartmentation Survey Services
Fire compartmentation is a critical element of building safety, designed to contain the spread of fire and smoke, giving occupants time to evacuate and limiting property damage. Our comprehensive fire compartmentation surveys ensure that your building’s fire safety measures are fully compliant with the latest regulations and standards.
During the survey, our experienced specialists will assess your fire compartment walls, floors, ceilings, and doors to identify any gaps, weaknesses, or breaches in the fire barriers. We will also review the integrity of fire-resistant materials and make sure that all fire doors are properly fitted and functional.
Key components of our fire compartmentation survey include:
Visual Inspection
A thorough check of the building's fire-rated partitions, doors, and structural elements to identify potential risks.
Testing & Assessment
Evaluation of fire-rated doors, seals, and intumescent coatings to ensure they meet the required standards.
Compliance Review
We will compare the building’s fire compartmentation against current fire safety regulations, such as those outlined by the Regulatory Reform (Fire Safety) Order 2005 and BS 9999.
Fire Stopping Services
Fire stopping services are a critical component of fire protection and building safety. These services involve the installation of materials and systems designed to prevent the spread of fire and smoke within a building. They are typically used to seal gaps, joints, and openings in fire-rated walls, floors, and ceilings, as well as around building penetrations like pipes, cables, ducts, and electrical services. The goal is to maintain the integrity of fire-resistance-rated assemblies, prevent the spread of fire, and protect both occupants and the building structure.
Key Aspects of Fire Stopping Services:
-
1. Check the Door Leaf (Main Door)Condition of the Door: Look for any physical damage, such as holes, cracks, or dents, that could compromise the integrity of the door. Certification Label: Ensure the fire door has a visible fire-resistance label or marking indicating the fire rating (e.g., FD30 meaning 30 minute fire door, FD60 meaning 60 minute fire door) which tells you how long the door can withstand fire. Proper Fit: The door should fit within the frame without significant gaps. A poorly fitting door can reduce its fire-resistant capabilities.
-
2. Check the Door FrameCondition: Inspect for damage, including cracks or missing parts of the frame. Sealant: Ensure the frame is sealed appropriately, and there are no gaps where smoke or flames could pass through.
-
4. Check the Door SealsIntumescent Seals: These seals expand when exposed to heat, sealing the door to the frame to prevent smoke and fire from passing through. Check for any signs of damage or wear. Smoke Seals: These are separate from the intumescent seals and should be intact and undamaged to prevent the passage of smoke during a fire.
-
5. Check the Door’s OperationEase of Movement: The door should open and close easily without any obstruction or sticking. It should not require excessive force to operate. Clearance: There should be no more than a small gap (usually 3mm) between the door and the frame when the door is fully closed.
-
1. Check the Door Leaf (Main Door)Condition of the Door: Look for any physical damage, such as holes, cracks, or dents, that could compromise the integrity of the door. Certification Label: Ensure the fire door has a visible fire-resistance label or marking indicating the fire rating (e.g., FD30 meaning 30 minute fire door, FD60 meaning 60 minute fire door) which tells you how long the door can withstand fire. Proper Fit: The door should fit within the frame without significant gaps. A poorly fitting door can reduce its fire-resistant capabilities.
-
2. Check the Door FrameCondition: Inspect for damage, including cracks or missing parts of the frame. Sealant: Ensure the frame is sealed appropriately, and there are no gaps where smoke or flames could pass through.
-
4. Check the Door SealsIntumescent Seals: These seals expand when exposed to heat, sealing the door to the frame to prevent smoke and fire from passing through. Check for any signs of damage or wear. Smoke Seals: These are separate from the intumescent seals and should be intact and undamaged to prevent the passage of smoke during a fire.
-
5. Check the Door’s OperationEase of Movement: The door should open and close easily without any obstruction or sticking. It should not require excessive force to operate. Clearance: There should be no more than a small gap (usually 3mm) between the door and the frame when the door is fully closed.
Importance of Fire Stopping
Safety
Fire stopping helps contain fire within the area of origin, providing valuable time for occupants to evacuate and for firefighters to control the blaze.
Property Protection
It helps reduce the potential for extensive damage by preventing the spread of fire, smoke, and heat.
Compliance
Many building codes require fire stopping to ensure fire-rated barriers remain intact, which is critical for passing safety inspections.
In summary, fire stopping services are essential for protecting buildings from the spread of fire, ensuring the safety of occupants, and complying with regulatory standards. Whether in new construction or retrofitting, a well-executed fire stopping system is a critical element of fire safety planning
Services Offered
Design and Consultation
Expert evaluation of building plans and fire stopping requirements.
Installation
Professional installation of fire stopping materials in line with building codes and safety standards.
Maintenance and Inspections
Periodic checks to ensure that fire stopping measures remain intact and functional.
Retrofitting
Installing fire stopping solutions in existing buildings that may not have been built with fire protection in mind.
